მუხლუხა ექსკავატორი

HMK 310 LC

HMK 310 LC

HMK 310 LC

ბრენდი HIDROMEK

HMK 310 LC Bénéficiant d'une construction renforcée pour les usages intensifs et conçue dans une optique de performances maximales, de longévité et de fonctionnement sans encombre dans des conditions de terrain difficiles, les pelles hi̇dromek sont plus durables grâce aux améliorations apportées à la nouvelle série h4.

  • General Information

    More work within less time

    17 % More productive*

    Shortening the work cycle time with bigger bucket capacity and speed, H4 Series carry the productivity to the top level with their new technology.

    7% More efficient*

    With improvements to the attachment and hydraulic group, H4 Series excavators ensure more work within less time.

    10% Faster *

    With faster hydraulic movements due to developed hydraulic system design, H4 Series excavators ensure more work within less time.

    HİDROMEK’s modern production facilities and going through sensitive quality-control processes, H4 Series excavators have excellent durability.

    Safe working environment

    ROPS&FOPS cabin

    Having the standards of ROPS (Roll Over Protective Structure) & FOPS (Falling Object Protective Structure), H4 Series excavators provide maximum safety and durability.

    Wide vision capacity

    Designed with giving special importance to occupational safety, H4 Series ensure excellent vision by minimizing the blind spot on the side and rear cameras. Along with the increase in the number of led headlights, the night vision is significantly improved on H4 Series excavators; in addition, there are also red handles and warning labels providing maximum safety for the operator.

    Audio warning systems

    H4 Series excavators enable safer working environment with their automatic starting horn, swing warning system and travel warning system.

    *The data are prepared in comparison with the previous serie in HP mode.

სპეციფიკაციები

OPERATING WEIGHT

OPERATING WEIGHT 31.600 kg

ENGINE

Maximum Power 239 HP (178 kW) @1900 rpm
Maximum Torque 1014 Nm @1400 rpm
Brand - Model ISUZU-GH-6HK1X
Type Water-cooled, 4 cycle, 6 cylinders, line type direct injection, turbocharger, intercooler, electronic diesel engine
Number of cylinders 6
Bore x Stroke 115 mm x 125 mm
Displacement 7790 cc

HYDRAULIC SYSTEM

Pump Type 2 axial piston type pumps with doublevariable displacement and inclined plate
Maximum Flow 2 x 259 L/min
Pilot Pump 27 L/min
Attachment 350 kgf/cm2
Power Boost 380 kgf/cm2
Travel 350 kgf/cm2
Swing 285 kgf/cm2
Pilot 40 kgf/cm2

SWING SYSTEM

Swing Speed 10,4 rpm

TRAVEL

High Speed 5,1 km/h
Low Speed 3,0 km/h

DIGGING PERFORMANCE

Bucket Digging Force (ISO) 19.600 (21.300) kgf
Bucket capacity 1,6 m3
Arm Breakout Force (ISO) 16.400 (17.800) kgf

WORKING DIMENSIONS

Boom Dimension 6.280 mm
Arm Dimension 2.500 mm
Maximum Digging Depth 6.760 mm
Maximum Reach at Ground Level 10.150 mm
